| Name: | ZJS-A automatic capsule counting machine |
|---|---|
| Inquire |
Product Description
Intelligent automatic capsule counting and filling machine.
Proprietary technology, PLC control, touch screen operating system count automatically and high-accuracy, put bottle by conveyer belt and fill medicine automatically, high differentiate rate, fast responding speed.
Some accessory equipments can be connected like feeding turntable, capping machine and
Labeling machine and so on.
This machine is widely applied for capsule counting for small scale production in hospital,
Small pharmaceutical factory etc.
Counting capacity | 20000 – 40000 capsules/hour |
Suitable capsule size | # 000, # 00L, # 00, # 0L, # 0, #1, # 2, # 3, # 4 And # 5. The machine uses locked capsule. |
Maximum bottle in diameter | 130 mm |
Filling nozzle size | 25 mm or customization |
Accounting precision | 100 % |
Mould changing time | 5 minutes |
Compressed air | 0.03 m3/min, 0.7 Mpa |
Power supply | AC, 220V/50HZ 1 phase or customization |
Power | 1.2 KW |
Overall size | 1200 x 500 x 1400 mm |
Net weight | 90 kg |
